MOTOTRBO Atex Digital Radio
The MOTOTRBO Atex Digital Radio DP4000 Ex Series combines the best of two-way radio functionality with the latest digital technology. These high-performing portables have the highest ATEX gas explosion group rating. Ideal for hazardous work with loud noise, long shifts, rough weather and dangerous conditions including combustible dust, explosive chemicals, gas leaks, flammable hydrocarbons and more.
Use Motorola’s Application Developer Program to adapt the DP4000 Ex Series to your unique needs in the future – from location tracking using the built-in GPS receiver to text messaging or call logging and recording. When you want to share information or pinpoint crew locations, access all the right applications on one device.
An integrated man-down and lone worker feature sends an instant alert if a mishap occurs. And the bright blue colour helps ensure workers can easily identify and carry only ATEX-approved radios into hazardous environments
MOTOTRBO Atex Digital Radio’s IP Site Connect uses the Internet to extend coverage to workers anywhere in the world and the single-site Capacity Plus expands capacity to over 1,000 users.
| DP4801 Ex | DP4401 Ex | |
|---|---|---|
| with Display | without Display | |
| Frequency Band | UHF B1 (403-470MHz) | UHF B1 (403-470MHz) |
| and VHF (136-174MHz) | and VHF (136-174MHz) | |
| Zone Capacity | 250 | 2 |
| Max. . Channels or | 1000 | 32 |
| Personality Capacity | ||
|
|
|
| Dimensions (H x W x L) with | 138.5 x 56.7 x 39.8mm | 138.5 x 56.7 x 37.8mm |
| Li-Ion battery | ||
| Weight with Li-Ion battery | 482.5g | 455.5g |
| Power Supply | 7.4 V Nominal | 7.4 V Nominal |
| FCC Description | UHF B1: ABZ99FT4091 | UHF B1: ABZ99FT4091 |
| >VHF: ABZ99FT3089 | VHF: ABZ99FT3089 | |
| Programmable Buttons | 5 | 3 |
| UHF: | UHF: | |
| IC Description | 109AB-99FT4091 | 109AB-99FT4091 |
| VHF: | VHF: | |
| 109AB-99FT3089 | 109AB-99FT3089 | |
| Gas Rating | ATEX: II 2G Ex ib | ATEX: II2GExib |
| IIC T4 Gb | IIC T4 Gb | |
| IECEx: Ex ibIICT4Gb | IECEx: ExibIICT4Gb | |
| Dust Rating | ATEX: II 2D Ex ib | ATEX: II 2D Ex ib |
| IIIC T130 °C Db | IIIC T130 °C Db | |
| IECEx: Ex ib IIIC | IECEx: Ex ib IIIC | |
| Mining Rating | ATEX: I M2 Ex | ATEX: I M2 Ex |
| ib I Mb | ib I Mb | |
| IECEx: Ex ib I Mb | IECEx: Ex ib I Mb | |
| Ingress Protection (IP) Rating | IP67* | |
| Battery life with IMPRES | ||
| Li-Ion (5/5/90 duty cycle) | 16 hrs | 16 hrs |
| Note: No GOB, No GPS, | ||
| Li-Ion (5/5/90 duty cycle) | 19 hrs | 19 hrs |
| Note: No GOB, No GPS, Digital |
DP4801 Ex – Adds a full keypad and large colour display for access to advanced features like texting and caller ID
DP4401 Ex – Rugged, easy to use, non-display model
The basic package includes: 2075mAh (Typical) Li-ion Battery (NNTN8359_) IMPRES Single-Unit Charger Antenna Dust Cover (15012157001) 2.5″ Belt Clip (PMLN6086_) In-box Documentation NOTE: The 24 months warranty only applies to the radio, it does not apply to batteries or accessories shipped within the model package
